1. Basic informations:

1) Feeding material information:

   a. Scrap steel

   b. Capacity: 30-100 TPH

   c. Status: baled or loose

2) Land information:

   L*W*H (around 100-150m*20-30m*8-12m)

   Without roof

3) Power requirement

    Shredding system around 450-10000 kW

    Magnet sorting system around 100 kW

4) Main Equipment and its function

    Hammer mill shredder(size reduction)

    Zig zag Air separator(remove light materials like dust)

    Dual Drum magnetic separator(recovery ferrous metal)

    Man picking station(pick out meatball, large items)

    Stacking conveyor(pile the clean ferrous metal)

5) Special design

    Whole plant with CE certificate

    Hammer mill sound proof to reduce noisy

    De-dusting system to keep the plant less dust pollution

    Dual drum magnetic separator system to clean the ferrous metal
